Model name |
22B2HM |
Panel |
21.5″ (VA) |
Pixel Pitch (mm) |
0.2493 (H) × 0.241 (V) |
Effective Viewing Area (mm) |
478.66 (H) × 260.28 (V) |
Brightness (typical) |
250 cd/m² |
Contrast Ratio |
3000 : 1 (Typical) 20 Million : 1 (DCR) |
Response Time |
6.5ms (GtG(BW)) |
Viewing Angle |
178° (H) / 178° (V) (CR > 10) |
Color Gamut |
NTSC 96% (CIE1976) / sRGB 116% (CIE1931) |
Color Accuracy |
– |
Optimum Resolution |
1920 × 1080 @ 75Hz – HDMI 1920 × 1080 @ 60Hz – VGA |
Display Colors |
16.7 Million |
Signal Input |
VGA × 1, HDMI 1.4 × 1 |
HDCP Version |
– |
USB Hub |
no |
Power Supply |
19VDC, 1.0A |
Power Consumption (typical) |
20W |
Speakers |
no |
Line in & Earphone |
Earphone |
Wall-Mount |
100mm × 100mm |
Adjustable Stand |
Tilt: -5° ~ 20° |
Product without Stand (mm) |
284.9 (H) × 492.2 (W) × 37.6 (D) |
Product with Stand (mm) |
380 (H) ×492.2 (W) × 162.9 (D) |
Product without Stand (kg) |
2.01 |
Product with Stand (kg) |
2.29 |
Cabinet Color |
Black |
