Socket | LGA1700 |
---|---|
Memory Type | DDR4 |
Form Factor | mATX |
Brand | ASRock |
CPU | – Supports 13th Gen & 12th Gen and next gen Intel® Core™ Processors (LGA1700) – 6+1+1 Power Phase design – Supports Intel® Hybrid Technology – Supports Intel® Turbo Boost Max 3.0 Technology |
Chipset | – Intel® H610 |
Memory | – Dual Channel DDR4 Memory Technology – 2 x DDR4 DIMM Slots |
Graphics | – Intel® Xe Graphics Architecture (Gen 12) – Dual graphics output: support HDMI and D-Sub ports by independent display controllers – Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096×2160) @ 60Hz – Supports D-Sub with max. resolution up to 1920×1200 @ 60Hz – Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible Port |
Audio | – 7.1 CH HD Audio (Realtek ALC897 Audio Codec) – Supports Surge Protection |
LAN | – PCIE x1 Gigabit LAN 10/100/1000 Mb/s – 1 x Realtek RTL8111H – Supports Wake-On-LAN – Supports Lightning/ESD Protection – Supports Energy Efficient Ethernet 802.3az – Supports PXE |
Slots | – 1 x PCIe 4.0 x16 Slot (PCIE2), supports x16 mode – 1 x PCIe 3.0 x1 Slot (PCIE1) |
Storage | – 4 x SATA3 6.0 Gb/s Connectors – 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) mode (Gen4) |
Connector | – 1 x SPI TPM Header – 1 x Chassis Intrusion and Speaker Header – 1 x CPU Fan Connector (4-pin)* – 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** – 1 x 24 pin ATX Power Connector – 1 x 8 pin 12V Power Connector – 1 x Front Panel Audio Connector – 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) – 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection) |
Rear Panel I/O | – 1 x PS/2 Mouse/Keyboard Port – 1 x D-Sub Port – 1 x HDMI Port – 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) – 4 x USB 2.0 Ports (Supports ESD Protection) – 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) – HD Audio Jacks: Line in / Front Speaker / Microphone |
Form Factor | – Micro ATX Form Factor: 8.66-in x 7.6-in, 22.0 cm x 19.3 cm – Solid Capacitor design |
OS | – Microsoft® Windows® 10 64-bit / 11 64-bit |
