| Socket | LGA1700 |
|---|---|
| Brand | Intel |
| Product Collection | 12th Generation Intel® Core™ i5 Processors |
| Code Name | Alder Lake |
| Processor Number | i5-12400 |
| Total Cores | 6 |
| # of Performance-cores | 6 |
| # of Efficient-cores | 0 |
| Total Threads | 12 |
| Max Turbo Frequency | 4.40 GHz |
| Performance-core Max Turbo Frequency | 4.40 GHz |
| Performance-core Base Frequency | 2.50 GHz |
| Cache | 18 MB Intel® Smart Cache |
| Total L2 Cache | 7.5 MB |
| Processor Base Power | 65 W |
| Maximum Turbo Power | 117 W |
| Max Memory Size (dependent on memory type) | 128GB |
| Memory Types | Up to DDR5 4800 MT/s Up to DDR4 3200 MT/s |
| Processor Graphics | Intel® UHD Graphics 730 |
| Graphics Base Frequency | 300 MHz |
| Graphics Max Dynamic Frequency | 1.45 GHz |
| PCI Express Revision | 5.0 and 4.0 |
| Sockets Supported | LGA 1700 |
| DeepCool AG200 | |
| Product Dimensions | 119×77×133 mm |
| Heatsink Dimensions | 94×57×133 mm |
| Net Weight | 304g |
| Heatpipe | Ø6 mm×2 pcs |
| Fan Dimensions | 92×92×25 mm |
| Fan Speed | 500~3050 RPM±10% |
| Fan Airflow | 36.75 CFM |
| Fan Air Pressure | 2.89 mmAq |
| Fan Noise | ≤30.5 dB(A) |
| Fan Connector | 4-pin PWM |
| Bearing Type | Hydro Bearing |
| Fan Rated Voltage | 12 VDC |
| Fan Rated Current | 0.13 A |
| Fan Power Consumption | 1.56 W |
