| Socket | LGA1200 |
|---|---|
| Memory Type | DDR4 |
| CPU (MAX SUPPORT) | up to i9 |
| SOCKET | 1200 |
| CHIPSET | Intel® H510 Chipset |
| DDR4 MEMORY | 3200(MAX) / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz |
| MEMORY CHANNEL | Dual |
| DIMM SLOTS | 2 |
| MAX MEMORY (GB) | 64 |
| PCI-E X16 | 1 |
| PCI-E GEN | Gen4 |
| PCI-E X1 | 1 |
| SATAIII | 4 |
| M.2 SLOT | 2 |
| TPM (HEADER) | 1 |
| LAN | 1x Intel® I219V Gigabit LAN controller |
| USB 3.2 PORTS (FRONT) | 2(Gen 1, Type A) |
| USB 3.2 PORTS (REAR) | 2(Gen 1, Type A) |
| USB 2.0 PORTS (FRONT) | 2 |
| USB 2.0 PORTS (REAR) | 4 |
| SERIAL PORTS(FRONT) | 1 |
| AUDIO PORTS (REAR) | Realtek® ALC897 Codec |
| VGA | 1 |
| HDMI | 1 |
| DIRECTX | 12 |
| FORM FACTOR | Mirco-ATX |
| OPERATING SYSTEM | Support for Windows® 10 64-bit |
