| 80PLUS® | Bronze |
| Fan Information | Fan Size: 120 mm Fan Control: Seasonic S2FC Fan Bearing: Sleeve bearing Life Expectancy: 30,000 hours at 40 °C, 15 % – 65 % RH |
| Cable Information | Modularity: Fixed cable Cable type: Flat black cables |
| Electrical Features | Operating Temperature: 40 °C MTBF @ 25 °C, excl. fan: 100,000 hours AC Input: Full Range |
| Protection | Over Power Protection (OPP) Over Voltage Protection (OVP) Under Voltage Protection (UVP) Short Circuit Protection (SCP) |
| Connector | Connector Count |
|---|---|
| Main Power (24/20 pins) | 1 |
| CPU (8/4 pins) | 1 |
| PCIe (8/6 pins) | 4 |
| SATA | 6 |
| Peripheral | 3 |
| Floppy | 1 |
