Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000 G-Series, 3000 Series, 3000 G-Series, 2000 Series, 2000 G-Series and 1000 Series Desktop Processor and Athlon™ with Radeon™ Vega Graphics desktop processors
CHIPSET
AMD® B450 Chipset
MEMORY
2 x DDR4 memory slots, support up to 64GB *ComboPI 1.0.0.3-based and above BIOS are required.
2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466 MHz (by A-XMP OC MODE)
SLOTS
1 x PCIe 3.0 x16 slot
PCIe 2.0 x1 slot
ONBOARD GRAPHICS
1 x DVI-D port, supports a maximum resolution of 1920×1200@60Hz
1 x HDMI™ 2.0b with HDR port, supports a maximum resolution of 4K @60Hz
STORAGE
4 x SATA 6Gb/s ports
1x M.2 slot (Key M)
USB
6x USB 3.2 Gen1 (SuperSpeed USB) ports (4 ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 (High-speed USB) ports (2 ports on the back panel, 4 ports available through the internal USB connectors)
AUDIO
Realtek® ALC892/ALC897 Codec
LAN
1 x Realtek® 8111H Gigabit LAN controller
INTERNAL CONNECTORS
1x 24-pin ATX main power connector
1x 4-pin ATX 12V power connector
4x SATA 6Gb/s connectors
2x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
1x USB 3.2 Gen1 connector (supports additional 2 USB 3.2 Gen1 ports)
1x 4-pin CPU fan connector
1x 4-pin system fan connector
1x Front panel audio connector
2x Front panel connectors
1x TPM module connector
1x Chassis Intrusion connector
1x Serial port connector
1x Clear CMOS jumper
BACK PANEL PORTS
Mouse
DVI-D Port
USB 3.2 Gen1
LAN Port
Keyboard
HDMI™ Port
USB 2.0 Ports
HD Audio Connectors
DIMENSIONS
9.3 in. x 7.9 in. (23.6 cm x 20.0 cm)
m-ATX Form Factor
