MSI B550M PRO-VDH WIFI

Availability:

Out of stock


  • Form Factor: mATX
  • Socket: AM4 (Ryzen 2000, 3000, 4000, 5000 series)
  • Memory Type: DDR4
  • RAM Slot: 4
  • SATA Port: 4
  • M.2 Slot: 2 (1x Gen4, 1x Gen3)
  • Display Connector: HDMI, VGA, DP
  • WiFi/Bluetooth: 2.4/5GHz, Bluetooth 4.2
  • 3-Pin ARGB Sync: Yes

SOLD OUT

Out of stock

Compare
Socket

AM4

Memory Type

DDR4

Brand

MSI

Form Factor

mATX

CPU (MAX SUPPORT) Support for 3rd Gen AMD® Ryzen™ processors and future AMD® Ryzen™ processors with BIOS update
SOCKET AMD Socket AM4
CHIPSET AMD® B550 Chipset
DDR4 MEMORY 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200/ 3466/ 3600/ 3733/ 3866/ 4000/ 4133/ 4266/ 4400 + Mhz by JEDEC and A-XMP OC MODE
MEMORY CHANNEL Dual
DIMM SLOTS 4
MAX MEMORY (GB) 128
PCI-E X16 1
PCI-E GEN Gen4 / Gen3
PCI-E X1 2
SATAIII 4
M.2 SLOT 2
RAID 0/1/10
TPM (HEADER) 1
LAN 1x Realtek® RTL8111HN Gigabit LAN
WIFI & BLUETOOTH Y
USB 3.2 PORTS (FRONT) 1(Gen 1, Type C), 2(Gen 1, Type A)
USB 3.2 PORTS (REAR) 4(Gen 1, Type A)
USB 2.0 PORTS (FRONT) 4
USB 2.0 PORTS (REAR) 2
SERIAL PORTS(FRONT) 1
AUDIO PORTS (REAR) Realtek® ALC892/ALC897 Codec
DISPLAYPORT 1
VGA 1
HDMI 1
DIRECTX 12
OPERATING SYSTEM Support for Windows® 10/11 64-bit
FORM FACTOR MATX
