| CPU (Max Support) | up to Ryzen 9 |
| Socket | AM4 |
| Chipset | AMD® B450 Chipset |
| DDR4 Memory | 1866/ 2133/ 2400/ 2667Mhz (by JEDEC) For AMD Ryzen Gen3 (R5/R7/R9) 2667/2800/2933/3000/3066/3200/3466/3733/3866 by A-XMP OC mode For AMD Other CPU 2667/2800/2933/3000/3066/3200/3466 by A-XMP OC mode |
| Memory Channel | Dual |
| DIMM Slots | 4 |
| Max Memory (Gb) | 128 |
| PCI-E X16 | 1 |
| PCI-E X1 | 2 |
| Sata III | 4 |
| M.2 Slot | 1 |
| TPM (Header) | 1 |
| Lan | 1x Realtek® 8111H Gigabit LAN controller |
| Usb 3.2 Ports (Front) | 2 (Gen1, Type A) |
| Usb 3.2 Ports (Rear) | 4 (Gen1, Type A) |
| Usb 2.0 Ports (Front) | 4 |
| Usb 2.0 Ports (Rear) | 4 |
| Serial Ports(Front) | 1 |
| Parallel Port(Front) | 1 |
| Audio Ports (Rear) | Realtek® ALC892/ALC897 Codec |
| DVI-D | 1 |
| VGA | 1 |
| HDMI | 1 |
| DirectX | 12 |
| Form Factor | m-ATX |
