| Model | M.2 NVMe Gen3 |
|---|
| Capacity | 512GB |
| Form factor | M.2 2280 |
| NAND Flash | 3D NAND |
| Controller | RTS5766DL |
| Dimensions (L x W x H) | 80 x 22 x 2.15mm / 3.15 x 0.87 x 0.09inch |
| Weight | 6.2g / 0.22oz |
| Interface | PCIe Gen3 x4 |
| Sequential Read (Max) | Up to 2,400MB/s* |
| Sequential Write (Max) | Up to 1,800MB/s* |
| 4KB Random Read IOPS(Max) | Up to 200K* |
| 4KB Random Write IOPS(Max) | Up to 150K* |
| Operating temperature | 0°C – 70°C |
| Shock resistance | 1500G/0.5ms |
| MTBF | 1,500,000 hours |
| Terabytes Written (TBW) | 520TB |
