| PROCESSOR | Supports 10th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors1
Processor socket LGA1200 |
| CHIPSET | Intel® H510 Chipset |
| MEMORY | 2x DDR4 memory slots, support up to 64GB |
| EXPANSION SLOT | 1x PCIe 3.0 x16 slot (From CPU) 1x PCIe 3.0 x1 slot (From PCH) |
| ONBOARD GRAPHICS | 1x VGA port 1x HDMI |
| STORAGE | 4x SATA 6Gb/s ports (From H510 Chipset) 1x M.2 slot (Key M, from H510 chipset) |
| USB | 4x USB 3.2 Gen 1 5Gbps ports (2 Type-A ports on the back panel, 2 ports available through the internal USB connector)
6x USB 2.0 ports (4 Type-A ports on the back panel, 2 ports available through the internal USB 2.0 connector) |
| AUDIO | 7.1-Channel High Definition Audio |
| LAN | 1x Realtek® RTL8111 Gigabit LAN controller |
| INTERNAL CONNECTORS |
|
| BACK PANEL PORTS | HDMI VGA Mouse / Keyboard USB 3.2 Gen 1 5Gbps Type-A LAN port Audio connector USB 2.0 USB 2.0 |
| DIMENSIONS | m-ATX Form Factor 9.3 in. x 7.95 in. (23.6 cm x 20.2 cm) |
