Brand | ASRock |
---|---|
Model | Intel Arc Battlemage |
Graphics Engine | Intel® Arc™ B580 Graphics |
Bus Standard | PCI® Express4.0 x8 |
DirectX | 12 Ultimate |
OpenGL | 4.6 |
Memory | 12GB GDDR6 |
Engine Clock | 2800 MHz |
Intel® XMX Engines | 160 |
Memory Clock | 19 Gbps |
Memory Interface | 192-bit |
Interface | 1 x DisplayPort 2.1 (Primary, up to UHBR13.5) 2 x DisplayPort 2.1 (Up to UHBR10) 1 x HDMI 2.1a |
HDCP | Yes |
Multi-view | 4 |
Recommended PSU | 650W |
Power Connector | 2x 8-pin |
Dimensions | 298 x 131 x 51 mm, 2.6-slot |
Net Weight | 959 g |
