| Brand | Cooler Master |
|---|---|
| PSU Form Factor | ATX |
| Model | MPE-7501-ACAAW |
| ATX Version | ATX 12V V2.52 |
| PFC | Active PFC |
| Input Voltage | 100-240V |
| Input Current | 10-6A |
| Input Frequency | 50-60Hz |
| Dimensions (L x W x H) | 140 x 150 x 86 mm |
| Fan Size | 120mm |
| Fan Bearing | HDB |
| Fan Speed | 2400 RPM |
| Noise Level @ 20% | 11.12 dBA |
| Noise Level @ 50% | 20.3 dBA |
| Noise Level @ 100% | 39.5 dBA |
| Efficiency | 85% Typically |
| 80 PLUS Rating | 80 PLUS Bronze |
| ErP 2014 Lot 3 | Yes |
| Operating Temperature | 40°C |
| Power Good Signal | 100 – 500 ms |
| Hold Up Time | >14ms at 100% Full Load |
| MTBF | >100,000 Hours |
| Protections | OVP, OPP, SCP, UVP, OTP |
| Regulatory | CCC, CE, TUV-RH, RCM, EAC, cTUVus, FCC, BSMI, KC, CB |
| Connectors | ATX 24 Pin Connectors x1 EPS 4+4 Pin Connectors x1 EPS 8 Pin Connector x1 SATA Connectors x8 Peripheral 4 Pin Connectors x4 PCI-e 6+2 Pin Connectors x`4 |
| Series | MWE Bronze Series |
