Boost Clock: Up to 3320 MHz
Game Clock: Up to 2780MHz
Stream Processors
2048
Compute Units
32 CUs (3rd Gen RT + 2nd Gen AI Accelerators)
Infinity Cache
32MB
Ray Accelerators
32
AI Accelerator
64
Memory Size/Bus
16GB/128 bit GDDR6
Memory Clock
20 Gbps Effective
Displays
Maximum 3 Displays
Interface
PCI-Express 5.0 x16
Output
2x HDMI®
1x DisplayPort™ 2.1a
Cooler Type
Tri-X Cooling
AeroCurve Fan Blade
Free Flow
Integrated Cooling Module
High TG Copper PCB
Optimized Composite Heatpipes
Two-Ball Bearing
Form Factor
2.7 slot, ATX
Dimension: 300(L)X 131(W)X 55(H)mm
Power Consumption
182W Typical Board Power
System Requirement
Minimum 650 Watt Power Supply
1 x 8-pin Power Connector.
PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
Minimum 8GB of system memory. 16GB recommended.
