Brand | Sapphire |
---|---|
Model | AMD RX 9000 Series |
GPU | AMD Radeon™ RX 9070 XT Graphics Card AMD RDNA™ 4 Architecture |
Engine Clock | Boost Clock: Up to 2970 MHz Game Clock: Up to 2400 MHz |
Stream Processors | 4096 |
Compute Units | 64 CUs (3rd Gen RT + 2nd Gen AI Accelerators) |
Infinity Cache | 64MB |
Ray Accelerators | 64 |
AI Accelerator | 128 |
Memory Size/Bus | 16GB/256 bit GDDR6 |
Memory Clock | 20 Gbps Effective |
Displays | 4 |
Resolution | HDMI®: 7680×4320 DisplayPort™ 2.1a: 7680×4320 |
Interface | PCI-Express 5.0 x16 |
Output | 2x HDMI® 2x DisplayPort™ 2.1a |
Sapphire Features | Honeywell PTM7950 Thermal Interface Material (TIM) AeroCurve Fan Blade Free Flow FrameDefense Integrated Cooling Module Tri-X Cooling Technology High TG Copper PCB Optimized Composite Heatpipes Metal Backplate Two-Ball Bearing Fans 14-Phase Digital Power Design Fuse Protection Intelligent Fan Control Precision Fan Control TriXX Supported TriXX Boost |
Accessories Bundled | L-Shape Support Bracket |
Form Factor | 3 slot, ATX Dimension: 320(L)X 120.25(W)X 61.6 (H)mm |
Power Consumption | 304W Typical Board Power |
System Requirement | Minimum 750 Watt Power Supply 2 x 8-pin Power Connector |
