Brand | Sapphire |
---|---|
Model | AMD RX 7000 Series |
GPU | AMD Radeon™ RX 7800 XT Graphics Card 5nm GPU AMD RDNA™ 3 Architecture |
Engine Clock | Boost Clock: Up to 2475 MHz Game Clock: Up to 2169 MHz |
Stream Processors | 3840 |
Compute Units | 60 CU (with RT+AI Accelerators) |
Infinity Cache | 64MB |
Ray Accelerators | 60 |
Memory Size/Bus | 16GB/256 bit GDDR6 |
Memory Clock | 19.5 Gbps Effective |
Displays | Maximum 4 Displays |
Resolution | HDMI™: 7680×4320 DisplayPort 2.1: 7680×4320 |
Interface | PCI-Express 4.0 x16 |
Output | 2x HDMI 2x DisplayPort |
Accessories Bundled | Graphics Card Supporter |
Cooler Type | 3 Fans |
Form Factor | 2.5 slot, ATX Dimension: 320(L)X 128.75(W)X 52.57 (H)mm |
Power Consumption | 270W Total Board Power |
System Requirement | Minimum 700 Watt Power Supply 2 x 8-pin Power Connector. PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard. Minimum 8GB of system memory. 16GB recommended. |
